FC8 Evo Fanless Chassis
The FC8 Evo is the next iteration of our acclaimed FC8 fanless chassis and with it comes a host of improvements and refinements that keeps this chassis on the cutting edge of design and performance.
The ultra-efficient heatsink has now been paired with our new direct touch heatpipes for even better cooling performance. The high grade aluminium extrusion is now finished with a fine sandblast texture and the front USB ports have been upgraded to support USB3.0*. Internal changes include easier drive assembly, support for an additional 2.5” drive and a universal optical drive eject button for added compatibility.
Just like its predecessor, the FC8 Evo is a perfect building block for any silent PC solution.
See our System Build Guide for more information and advice on using our range of chassis.
The ultra-efficient heatsink has now been paired with our new direct touch heatpipes for even better cooling performance. The high grade aluminium extrusion is now finished with a fine sandblast texture and the front USB ports have been upgraded to support USB3.0*. Internal changes include easier drive assembly, support for an additional 2.5” drive and a universal optical drive eject button for added compatibility.
Just like its predecessor, the FC8 Evo is a perfect building block for any silent PC solution.
See our System Build Guide for more information and advice on using our range of chassis.
Material: All aluminum, 4mm thick body
Available Colors: Silver / Black – sandblast finish
Motherboard Support: Mini ITX
Hard Drive Bays: 1 x 2.5″ + 1 x 3.5″ or 2.5″ (shared bay)
Optical Drive Bays: 1 x Slim slot loading drive, universal eject button
Front Ports: 2 x USB2.0 (*USB3.0 Ready, cable sold separately)
Expansion Slot: 1 x Low profile expansion card
Cooling: Heatpipe Direct Touch 4 Pipes – Max CPU TDP 95W**
Dimension: 240 x 250 x 100mm (W x D x H)
Power Supply: NanoPSU & AC Adapter (not Included)
Remote Control: MCE Compatible IR Receiver & Remote (not Included)
Net Weight: 2.5KG
**As with any passive cooling solution, environmental conditions will have an impact on the performance. A TDP of 95W is only recommended when the chassis is placed in a location with adequate air flow and moderate ambient room temperature
Available Colors: Silver / Black – sandblast finish
Motherboard Support: Mini ITX
Hard Drive Bays: 1 x 2.5″ + 1 x 3.5″ or 2.5″ (shared bay)
Optical Drive Bays: 1 x Slim slot loading drive, universal eject button
Front Ports: 2 x USB2.0 (*USB3.0 Ready, cable sold separately)
Expansion Slot: 1 x Low profile expansion card
Cooling: Heatpipe Direct Touch 4 Pipes – Max CPU TDP 95W**
Dimension: 240 x 250 x 100mm (W x D x H)
Power Supply: NanoPSU & AC Adapter (not Included)
Remote Control: MCE Compatible IR Receiver & Remote (not Included)
Net Weight: 2.5KG
**As with any passive cooling solution, environmental conditions will have an impact on the performance. A TDP of 95W is only recommended when the chassis is placed in a location with adequate air flow and moderate ambient room temperature
- FC8 Evo – Silent PC Review
The Streacom FC8 Evo is a compelling product that stands out with its attractive and compact form factor – read the full review
- FC8 Evo – Computer Base
Die Verarbeitungsqualität bewegt sich auf höchstem Niveau und konnte uns restlos überzeugen. – read the full review
- FC8 Evo – PC SK
Minimálne rozmery, pôsobivý dizajn a bezhlučná prevádzka výkonnej zostavy u nás predčili všetko ostatné. – read the full review
- FC8 Evo – TwojePC
Wykonanie obudowy Streacom FC8 Evo jest na bardzo wysokim poziomie. – read the full review
- FC8 Evo – 59 Hardware
Le Streacom FC8 Evo est à n’en point douter un boîtier luxueux : splendide, il dispose d’un niveau de finition inégalé même parmi les plus célèbres constructeurs connus du grand public. – read the full review
- FC8 Evo – Mad Shrimps
The FC8 Evo case from Streacom has a very clean, professional look and is ideal for people which want absolute silence when working at their PC – read the full review
- FC8 Evo – NikkTech
Long story short the FC8 EVO is one of the best mITX cases we’ve ever seen due to its Fanless design, excellent build quality and external PSU – read the full review
- FC8 Evo – TheLab.gr
Η ποιότητα πραγματικά είναι κορυφαία. Η εταιρία δεν τσιγκουνεύτηκε σε καμία περίπτωση τα υλικά, αλλά ούτε και τη τεχνογνωσία που έβαλε επάνω στο κουτί. – read the full review
- FC8 Evo – Techstation.it
Questo prodotto è assolutamente unico in termini di innovazione tecnica e i materiali sono ampiamente oltre lo standard dei migliori prodotti in commercio confermando le ottime abitudini qualitative di Streacom. – read the full review
- FC8 Evo – Razorman
Streacom juega la baza de un diseño realmente muy elegante y llamativo con esta caja Streacom Fc8 Evo que no desentonará ni mucho menos en cualquier salón. – read the full review
- FC8 Evo – Pure Overclock
Streacom’s FC8 EVO Fanless Chassis comes with a sleek, elegant and uniquely designed layout. It’s small foot print and silence experience is sure to create a conversation piece in your living room. – read the full review
- FC8 Evo – Ocaholic
The FC08 from Streacom is one of the best HTPC cases money can buy these days, especially if you’re looking for a passive cooled solution. The cooling is surprisingly effective. – read the full review
FC8 Evo - User Guide (English)
PDF - 1.1MB
FC8 Evo - Data Sheet (English)
PDF - 280K- FC8 Evo - Benutzerhandbuch (Deutsch)
PDF - 1.1MB - FC8 Evo - Datenblatt (Deutsch)
PDF - 280K
